Prefab Poultry House Commercial Chicken House

Prefab Poultry House Commercial Chicken HouseAdvantages of Senwang Commercial Chicken House:a. Good quality, service lif

Mobile:0086-18669803758 Email:qdsw87@qdswsteel.cn

Description


Prefab Poultry House Commercial Chicken House


Advantages of Senwang Commercial Chicken House:


a. Good quality, service life reach 10~15 years;

b. Easy to operate, easy to install and disassembly;

c. Save time and labor, one broiler shed just need one worker;

d. Save feed and water, raise the survival rate;

e. Engineers oversea service, we can send our engineers to your location for equipment installation guidance&debugging;

f. Free samples before placing the order, but we don't pay for the freight;

g. Quick response to your questions, best solutions to chicken raising, layout drawing for poultry shed construction and equipment installation;

h. Prompt reply to clients after-sale.

Layout considerations


1. The site should be chosen away from residential areas, with convenient transportation and away from the road.

2. The terrain is dry and sunny. As far as possible, it is not blocked in winter, with no wind in summer, and no water after rain. The area is large and there is room for development.

3. Water resources are rich and pollution-free, easy to access, and sufficient power is guaranteed.

4. The structure of the house is practical and economical. It not only saves funds but also saves energy. Its orientation is in line with local natural and physiological conditions. It is well lit, easy to ventilate, and easy to operate. Summer is good for heatstroke prevention and cooling, and winter is good for heat preservation and cold protection.

5. The layout of the premises should be reasonable so that the production area is separated from the non-production area. The non-production area and the water source are in the upwind direction of the chicken farm. The dirt road and the clean road are separated and do not cross. The manure field is located in the downwind direction of the chicken farm, and the brooding Separated from the breeding house, the brooding house is located in the upwind direction of the chicken farm.

6. Understand the local poultry epidemic situation and try to avoid infected areas or areas where there have been epidemics.

7. Avoid urban polluted areas and adopt appropriate environmental protection measures to minimize environmental pollution.

Parameter


Item Name

Materials Characteristics

Material Grade

Surface Treatment

Steel Column

H shape, Box, Steel Pipe, Hot rolled sheet

Q235B,Q345B

Paint or Hot dip Galvanized

Steel beam

H shape, Box, Steel Pipe, Hot rolled sheet

Q235B,Q345B

Paint or Hot dip Galvanized

Steel Bracing

Steel Rod, Steel Pipe, Angle Steel

Q235B,Q345B

Paint or Hot dip Galvanized

Steel Purlin

C or Z purlins(Thickness1.8mm~3.0mm)

Q235B,Q345B

Hot dip Galvanized

External Wall panels, Roof panels

Single colorful corrugate steel sheet, sandwich panels with EPS, Rock  wool, PU.

Galvanized Steel+ Painting

Alu-zin 150g,Fluorocarbon pain

Steel buildings Door

Sliding or Rolling door

Steel or Aluminum sheet

Paint or Hot dip galvanized

Steel buildings Windows

Aluminum alloy-Glass, Aluminum alloy-shutter

T=1.0-2.0mm

Alloy

Skylight panels

FRP T=1.5mm-1.8mm

Coefficient of thermal expansion:2.2x10-5/cm

Light Transmittance 85%

Ventilator

Turbine ventilator on a ridge

Steel, Stainless steel ,PC

Paint or Hot dip Galvanized

Gutter

Galvanized steel plate, Stainless steel plate

T=2.0mm

Hot dip galvanized

Downpipe

PVC pipe, color steel-pipe Y=0.5mm

Dia110mm

paint

Height Bolt

Ordinary ,High strength

10.9S,4.8S

Hot dip galvanized, Steel

Ground bolts

Steel RodM24,M27,M30,M33,M39,M42

10.9S

Steel
