Description
Compared with other residential building structure forms, steel structure houses are most suitable for factory production. The design, production, construction and installation of steel structure houses can be integrated through the BIM platform, changing "site construction" to "factory manufacturing". Improve the level of industrialization and commercialization of housing. At the same time, the steel structure house has light weight, low basic cost, convenient construction and installation, shortens the construction period, and can achieve dry work on site, reduce environmental pollution, and the materials can be recycled, which is in line with the environmental protection policy advocated by the state.
The steel structure building system is the best linker that can build the real estate industry, construction industry and metallurgy industry into a new industrial chain. The steel structure building system is a building system that can be assembled naturally, and its construction is less affected by the season. Compared with concrete structures, the construction period of steel structures is shorter (because the components are produced in factories). In addition, the steel structure can realize on-site dry operation, reduce environmental pollution, and the materials can be recycled.
Parameter
Product parameters
Material | Specification |
Length | With customer's requirement |
Width | Single span, double-span, Multi-span |
Height | With customer's requirement |
Column | Q235, Q345 welded H section steel |
Beam | Q235, Q345 welded H section steel |
Purlin | Q235 C channel or Z channel |
Knee brace | Q235 angle steel |
Vertical and transversal support | Q235 angle steel, round bar or steel pipe |
Tie bar | Q235 steel pipe |
Brace | Q235 round bar |
Cladding system | EPS, PU, Fiber Glass and Rock Wool sandwich panels or corrugated steel sheet with fiber glass wool insulation. available in Diferentcolors&gauges |
Partition wall | sandwich panels (EPS, PU, Fiber glass,Rock Wool etc.) available in Different colors&gauges |
Door | sandwich panel sliding door or roller door |
Gutter | stainless steel or color steel sheet |
Rainspout: | PVC |
Live load on roof | In 120kg/Sqm (Color steel panel surrounded) |
Wind resistance grade | 12 grades |
Earthquake-resistance | 8 grades |
Structure usage | Up to 50 years |
Finishing options | vast array of colors and textures available |
Paint Options | Alkyd paiting, two primary painting, two finish painting(gray paint, red paint, white paint, epoxy zinc etc.). Or Galvanized. |
Advantages of Senwang Steel Structure
1) First-rank structural steelwork construction qualification
2) Class A design qualification enterprises.
3) Has 1260 staff, 320 of them are technicians.
4) 15 first-grade registered architects.
5) 12 first-grade registered constructors.
6) 11 first-grade registered structural engineers.
7) We have built many projects in 68 countries.
8) Reliable engineer and technology workers team.
9) Overseas service and online technical support.
10) More than 30 years of manufacturing experience.
